Foundation cracks are not all equal -- their orientation, width, location, and rate of growth determine whether they represent a minor sealing concern or a structural emergency requiring immediate engineering intervention. Vertical cracks in poured concrete walls most commonly result from concrete shrinkage as the wall cures or from differential settlement as the soil beneath the footing compresses unevenly. These cracks are typically stable after they form and respond well to polyurethane or epoxy injection. Diagonal cracks that radiate from corners of window and door openings also frequently reflect normal settlement but should be monitored for width increase over time.
The repair method matched to horizontal cracks depends on the degree of deflection and the construction type of the wall. For poured concrete walls with deflection below critical thresholds, a carbon fiber strap system bonded to the wall face with structural epoxy provides a tensile reinforcement layer that counteracts the lateral earth pressure. For block walls, carbon fiber straps bonded to a plate assembly anchored into the slab and rim joist provide the same function. In both cases the straps are virtually invisible after installation and do not require interior space to accommodate them.
Epoxy injection and polyurethane injection are the two primary methods for sealing and structurally repairing cracks in poured concrete walls. Epoxy injection produces a bond that is actually stronger than the surrounding concrete, making it the correct choice for cracks where structural re-bonding of the two faces is the goal. The process involves drilling a series of small ports along the crack at intervals calculated to ensure complete penetration, installing surface-mounted injection ports, sealing the visible crack face between ports with epoxy paste, and pumping two-component structural epoxy resin under low pressure until it fully fills the void and appears at adjacent ports. The resin cures within the crack to a solid, high-strength bond that is permanent and fully water-resistant.
Soil settlement beneath footings is an independent cause of foundation cracks that requires evaluation separately from the wall repair itself. When soil compresses or washes out from beneath a footing, that section of the foundation wall loses its support and the wall may develop diagonal cracks as the unsupported section deflects downward. In these cases, crack injection addresses the symptom while leaving the root cause unresolved. Our assessment includes a review of grading, drainage, and visible footing conditions to identify signs that settlement is active. Where settlement is a factor, we coordinate the repair approach to address both the crack and the soil condition that created it, preventing recurrence after the crack is sealed.
From hairline seepage cracks to structural horizontal cracking, we have the right fix.
Every epoxy injection job is documented with before-and-after photos and a report of injection pressures and resin volumes consumed to verify full crack penetration.
Expanding polyurethane resin fills irregular crack voids completely, including geometry that epoxy cannot fully penetrate, and cures to a flexible seal that tolerates minor seasonal wall movement without reopening.
We calculate strap spacing and quantity based on the measured deflection, wall height, and soil pressure conditions at each job so the reinforcement is engineered for your specific wall rather than generically applied.
Where bowing wall deflection exceeds the threshold for carbon fiber repair alone, a wall anchor system provides mechanical resistance by connecting the deflecting wall to stable soil beyond the active failure zone through a tension rod and plate assembly.
Severe stair-step cracking that indicates ongoing settlement is evaluated for root cause before repair so we are not sealing a crack that will reopen as the movement continues.
We seal the floor-wall joint with a combination of hydraulic cement at active leak points and a flexible polyurethane sealant bead over the sealed joint to accommodate minor movement without allowing the seal to crack again.
Crack mapping, moisture readings, and wall plumb measurements are documented in a written report that accompanies your quote.
Written scope defines every material, method, and warranty term before you approve any work so there are no surprises on the invoice.
Our certified crew executes the repair to specification, maintaining injection pressure logs and documenting material volumes consumed to verify complete crack penetration.
A written warranty is issued on project completion, covering the repair against reoccurrence under normal conditions for the warranty period stated in your contract.
